1PC NEW ORIGINAL Industrial Servo Motor YASKAWA AC SERVO MOTOR 3000r/min 2.0A SGMAV-01A3A21

SEPCIFICATIONS

As energy costs rise, more emphasis is being placed on determining the health of large inductive motors. Motor Current Monitoring and Analysis (MCSA) is a straight forward tool to diagnosing problems with large inductive motors. This technique along with standard vibration analysis, voltage monitoring, and temperature monitoring provides a complete diagnostic perspective of motor health and condition, power consumption, and overall efficiency.

Alignment:

Align the shaft of the Servomotor with that of the equipment to be controlled, then connect the shafts with couplings. Install the Servomotor so that alignment accuracy falls within the range shown below.

NOTE

If the shafts are not aligned properly, vibration will occur, resulting in damage to the bearings.

Mechanical shock to the shaft end must be less than 98m/s2 (10G) and must be applied no more than twice.

Design the mechanical system so that thrust load and radial load applied to the servomotor shaft end during operation falls within the range shown in the following table.

Orientation:

Install the Servopack perpendicular to the wall as shown in the figure.

The Servopack must be orientated as shown in the figure because it is designed to be cooled by natural convection.

• Firmly secure the Servopack through three or four mounting holes.

Installation method:

a) Install Servopack perpendicular to the wall so that the front panel (containing connectors) faces outward.

b) Provide sufficient space around each Servopack to allow cooling by natural convection.

c) When installing Servopacks side by side, provide at least 10 mm space between them and at least 50 mm space above and below them as shown in the figure above. Install cooling fans above the Servopacks to prevent the temperature around each Servopack from increasing excessively and also to maintain the temperature inside the control panel evenly.

d) Maintain the following conditions inside the control panel:

• Ambient temperature for Servopack: 0 to 55°C

• Humidity: 90%RH or less • Vibration: 0.5G (4.9 m/s2)

• Condensation and freezing: None • Ambient temperature to ensure long-term reliability: 45°C or less
