    Emerson DO 24V DC Power Supply Module High Side CHARM 200mA Current Limiting Circuit Field Wiring Disconnect

    Ask Lasest Price
    Brand Name : Emerson
    Model Number : DO 24 V DC
    Price : negotiable
    Payment Terms : T/T
    Supply Ability : 100
    Delivery Time : 5-8 work days
    Certification : dose not supply
    • Product Details
    • Company Profile

    Emerson DO 24V DC Power Supply Module High Side CHARM 200mA Current Limiting Circuit Field Wiring Disconnect

    Emerson DeltaV™ DO 24 V DC High Side CHARM 200 mA Current Limiting Circuit, Field wiring disconnect

    Specifications:

    Device Type24 V DC Solenoid coils
    On State Output rating100 mA continuous @ 24 V DC
    Off-state Leakage Current1 mA maximum
    Line Fault DetectionGuaranteed short circuit: <50 Ω Load, Guaranteed good status: 240 Ω to 10 kΩ load, Guaranteed open circuit: >20 kΩ load
    Configurable Output BehaviorMomentary Output, Continuous Pulse Output, Line fault testing
    Line Fault Test Timing200 µsec
    Field Circuit Protection200 mA Current Limiting Circuit, Field wiring disconnect
    CHARM power req.116 mA max @ 24 V DC - Standard Terminal Block, 24 mA max @ 24 V DC - Relay Output Terminal Block

    CHARM Heat Dissipation

    Pulse Count - Pulse train 0.1 Hz to 10 KHz, 50 µsec min pulse width

    Features

    • Eliminate marshalling and add I/O anywhere in the plant without affecting control room cabinets
    • No marshalling cabinet or cross-wiring, fewer wires, much less work and fewer contact points for potential failures
    • No marshalling cabinet or cross-wiring, fewer wires, much less work and fewer contact points for potential failures

    Easily apply security using DeltaV built-in security features


    The DeltaV control network architecture creates a separate control system network completely segmented from other networks in the plant, delivering a system inherently protected from unauthorized external access.


    Reduce implementation effort with no-hassle security solutions


    DeltaV Smart Switches provide auto port lockdown to prevent unauthorized access to the network from switch ports.


    Monitor and manage network devices within the DeltaV system


    All routine system maintenance and troubleshooting is done from secured DeltaV workstations so physical access to equipment is not required.


    Improve system availability and reduce troubleshooting efforts


    All network equipment supplied with the DeltaV system is fully tested and supported by Emerson as part of DeltaV development.


    Easily integrate data The DeltaV DCS simplifies data integration …


    • At the device level: Plug-and-play capabilities exist for runtime and diagnostics in a variety of standard protocols.


    • To enterprise business systems: Connect via industry standard OPC along with built-in Service-Oriented Architecture (SOA) web services that provide connections to Emerson’s Manufacturing Execution System, Syncade™, and other systems.


    • Between the field and business systems: Connections are made with minimal setup time. Decision makers at every level in the plant can get the critical data they need, reliably, securely, and in real time.
