Industrial Servo Motor SGMJV-04AAA61 Yaskawa 400w Servo Motor
3000RPM 3PH 220V 400W
QUICK DETAILS
- Power : 400W
- Voltage : 200V
- Current : 2.7A
DESCRIPTION
- Yaskawa Electric
- AC Servo Motor
- Industrial Servo Motor
SEPCIFICATIONS
Brand Name : Yaskawa
Model Number : SGMJV-04AAA61
Type : Servo Motor
Frequency : 50/60Hz
Output Power : 50W
Protect Feature : Explosion-proof
Phase : Single-phase
Certification : CE
AC Voltage : 208-230 / 240 V
Place of Origin : Japan
Efficiency : IE 1
output : 400
output : 50
voltage : 240
voltage : 230
phase : 1
power supply : AC
protect feature : Explosion proof
Storage and Transportation
• Do not store or install the product in the following locations.
Failure to observe this caution may result in fire, electric shock,
or damage to the equipment.
• Locations subject to direct sunlight
• Locations subject to temperatures outside the range specified in
the storage/installation temperature condi-
tions
• Locations subject to humidity outside the range specified in the
storage/installation humidity conditions
• Locations subject to condensation as the result of extreme
changes in temperature
• Locations subject to corrosive or flammable gases
• Locations subject to dust, salts, or iron dust
• Locations subject to exposure to water, oil, or chemicals
• Locations subject to shock or vibration
• Do not hold the product by the cables, motor shaft, or encoder
while transporting it.
Failure to observe this caution may result in injury or
malfunction.
• Do not place any load exceeding the limit specified on the
packing box.
Failure to observe this caution may result in injury or
malfunction.
• If disinfectants or insecticides must be used to treat packing
materials such as wooden frames, pal-
lets, or plywood, the packing materials must be treated before the
product is packaged, and meth-
ods other than fumigation must be used.
Example: Heat treatment, where materials are kiln-dried to a core
temperature of 56
minutes or more.
If the electronic products, which include stand-alone products and
products installed in machines, are packed
with fumigated wooden materials, the electrical components may be
greatly damaged by the gases or fumes
resulting from the fumigation process. In particular, disinfectants
containing halogen, which includes chlo-
rine, fluorine, bromine, or iodine can contribute to the erosion of
the capacitors
Installation
• Never use the product in an environment subject to water,
corrosive gases, flammable gases, or
combustibles.
Failure to observe this caution may result in electric shock or
fire.
• Do not step on or place a heavy object on the product.
Failure to observe this caution may result in injury or
malfunction.
• Do not cover the inlet or outlet ports and prevent any foreign
objects from entering the product.
Failure to observe this caution may cause internal elements to
deteriorate resulting in malfunction or fire.
• Be sure to install the product in the correct direction.
Failure to observe this caution may result in malfunction.
• Provide the specified clearances between the SERVOPACK and the
control panel or with other
devices.
Failure to observe this caution may result in fire or malfunction.
• Do not apply any strong impact.
Failure to observe this caution may result in malfunction
