PLC Programmable Logic Controller GE Fanuc IC695PSA040F RX3i
PacSystem IC695PSA040 power supply
Product Description
The IC695PSA040 is a 120/240 volt AC or 125 volt DC, 40 Watt Power
Supply from the GE Fanuc RX3i Series. See specifications for this
unit on IC695PSA040's website page.
Technical Specifications
Output Power: 40 Watts max
Output Voltage: 24 VDC, 5.1 VDC or 3.3 VDC
Output Current: 0-1.6 A, 0-6 A, or 0-9 Amps
Rated Voltage: 120/240 VAC or 125 VDC
Input Voltage Range: 85 to 264 VAC or 100 to 300 VDC
Number of Slots: 2
Specifications
Nominal Rated Voltage Input Voltage Range AC DC | 120/240 VAC or 125 VDC
85 to 264 VAC 100 to 300 VDC |
Input Power (Maximum with Full Load) |
70 Watts maximum |
| Inrush Current | 4 Amps, 250 milliseconds maximum * |
| Output Power | 40 Watts maximum total 5.1 VDC = 30 Watts maximum 3.3 VDC = 30 Watts maximum The maximum total output power available depends on the surrounding
air temperature, as shown. |
| Output Voltage | 24 VDC: 19.2 VDC to 28.8 VDC 5.1 VDC: 5.0 VDC to 5.2 VDC (5.1 VDC nominal) 3.3 VDC: 3.1 VDC to 3.5 VDC (3.3 VDC nominal) |
| Output Current | 24 VDC: 0 to 1.6 Amps 5.1 VDC: 0 to 6 Amps 3.3 VDC: 0 to 9 Amps |
| Isolation (input to backplane): | 250 VAC continuous; 1500 VAC for 1 minute |
| Ripple (all outputs) | 150 mV |
| Noise (all outputs) | 150 mV |
| Ride-through time | 20 ms. This is the length of time the Power Supply maintains valid
outputs if the power source is interrupted |
| Wiring Terminals | Each terminal accepts one 14 AWG to 22 AWG wire. |
| Current per Terminal | 6 Amps |
| Number of Daisy-Chained PSA040 Supplies | Up to 4 |
Revision History
| Version | Date | Details |
| IC695PSA040J | May 2013 | Increases the margin of the 5V and 3.3V under voltage detectors to
prevent PS faults during power-up. |
| IC695PSA040H | Aug. 2012 | Resolves an issue with powering up under light loads. |
| IC695PSA040G | Jun. 2011 | Hardware modification improves radiated RF susceptibility and
removes the requirement to install control systems that use this
product in a grounded metal enclosure to meet the EU EMC Directive. |
| IC695PSA040F | Sep. 2006 | Hardware modification. Previous versions of this Power Supply
occasionally failed to power up when installed in a 16-Slot
Universal Backplane, IC695CHS016. This update resolves the issue. |
| IC695PSA040E | Mar. 2006 | The D version of this Power Supply (IC695PSA040D) incorrectly
reported that it was a PSA140 power supply, causing a Configuration Mismatch error. The E version and versions prior to D report their identification
correctly. |
| IC695PSA040A | Oct. 2005 | Initial release |
FAQs
What is an IC695PSA040?
The IC695PSA040 is a 120/240 VAC or 125 VDC, 40 Watt Power Supply
from the GE Fanuc RX3i Series.
From what input voltage source range does IC695PSA040 operate?
This power supply operates from an input voltage source range of 85
to 264 VAC or 100 VDC to 300 VDC.
What 3 outputs does this power supply have?
- +5.1 VDC output
- +24 VDC relay output that can be used to power circuits on Output
Relay modules
- +3.3 VDC which, is used internally by RX3i modules with IC695
catalog numbers
How many IC695PSA040's can be installed in a PACSystems RX3i
Universal Backplane?
Only 1
With what can IC695PSA040 not be used?
This power supply cannot be used with other RX3i power supplies in
redundant or increased capacity modes.
What do the 4 LEDs indicate?
Power (Green/Amber). When this LED is green, it indicates power is
being supplied to the backplane. When this LED is amber, power is
applied to the power supply, but the power supply switch is off.
P/S Fault (Red). When this LED is lit, it indicates the power
supply has failed and is no longer supplying sufficient voltage to
the backplane.
Over Temperature (Amber). When this LED is lit, it indicates the
power supply is near or exceeding its maximum operating
temperature.
Overload (Amber). When this LED is lit, it indicates the power
supply is near or exceeding its maximum output capability on at
least one of its outputs.
What should I do if my IC695PSA040 is not working properly?
Your IC695PSA040 may need repair .
